Developer Guide

Requirements

This whole application is written in javascript so NodeJs v8.0 is the minimal required installation.

Usage

First of all clone the repository here

Then install the dependencies

cd talk-control
npm i

Then run the project

npm start

Core concepts

TC-Server

In this system, tc-server is the backend, that act as the single source of truth. It stores the informations on the current slide and the total number of slides in the presentation. It will update his store with each event received from a master (see next section) and then dispatch other events with changes to notify masters. You can find the source code in src/server/.

Events fired

• initialized: fired once, the first time the server initialize its state. This initialization is triggered when an 'init' event is fired from a master.
• gotoSlide: fired every time the current slide changes in the state.

TC-Master

A master is the main controller of a view, it will mainly forward events between the server and its slaves. It displays the slave(s) and listens for speaker actions (key pressed, etc...), and forward the events to the server. There are multiple master views, like :

• The stage view : it displays the talk in an iframe in fullscreen.
• The presenter view : it displays the current slide, a preview of the next one, a timer and the notes attached to the current slide.

Events fired

To server

• init: when the main slave* is initialized
• keyboardEvent: every time a useful key is pressed

To slave

• init: when the master is initialized
• gotoSlide: forwarding the same event received from the server
• sendNotesToSlave: forwarding the notes given by a slave to the others who might need them

TC-Slave

A slave is a component with a specific job (for example : the slideshow, the timer, etc...) which updates itself whith the events fired by its master. The one acting as the main slave is the one who shows the current slide.

Events fired

• initialized : Only fired by the slaves which are contained in an iframe, when they're ready to start. The payload contains the number of slides and optionnaly an array of slides objects (like with Revealjs).
• sendNotesToMaster : Only fired by the main slave* every time it's current slide changes, it will send the attached notes to the master.

(*) the main slave is the one who shows the current slide

Engines

Engines are classes that handle all presentation frameworks (referred later as just framework) related process. There are two implementations of them for each frameword: one server side and one client side which will be instanciated on multiple slaves.

Server side engine will handle every input event received and update the state accordingly. It's the only one which has the knowledge about how a slide is represented by the framework.

Client side engine will interract with the framework to update the view when a gotoSlide event is received by the slave. It's the only one with the knowledge of interacting with the framework.

Global workflow

Here is a sequence diagram which illustrate the minimal global workflow of the application and events emitted by each part.

Contributing

See contributing.md
